SCO2W/SCO5W/SCO6WE- SCO Series -Water Jacketed Units – Shellab
Innovative peltier cooling technology,eliminates the need for a refrigeration compressor. The SRIP series use over 70% less power than alternative models and reduce room air conditioning loads by 75%. They also include strong shelves, which eliminates sagging.
$6,386.00 – $7,785.00
Contamination ControlExtensive use of copper in the CO2 sample port, humidity reservoir, heated CO2 feed line, and housing of the patented HEPA filtration system adds reassurance that foreign microbes will not affect test results. Cleanup is a breeze with the all stainless steel chamber, coved corners, and autoclavable door gasket. Optional copper shelves are available for even more contamination control.
| SCO CO2 Incubators Water Jacketed Series Specification Chart | ||||
| SCO2W | SCO5W | SCO6W | ||
| Interior Volume, Nominal | 1.5 cu.ft. (42 liters) | 5.1 cu.ft. (144 liters) | 5.9 cu.ft. (166 liters) | |
| Interior Dimensions W x D x H | 15.7″ x 15.7″ x 10.2″ 400 x 400 x 260 mm |
19.3″ x 19.8″ x 23.0″ 490 x 503 x 584 mm |
20.3″ x 19.8″ x 25.3″ 516 x 503 x 643 mm |
|
| Exterior Dimensions(w x d x h) | 21.0″ x 22.5″ x 27.0″ 534 x 572 x 686 mm |
26.0″ x 25.5″ x 40.3″ 660 x 648 x 1022 mm |
26.0″ x 26.3″ x 40.3″ 661 x 668 x 1024 mm |
|
| Interior Construction | 300 series stainless steel |
300 series stainless steel |
300 series stainless steel |
|
| Exterior Construction | 20 gauge steel, powder coated |
20 gauge steel, powder coated |
20 gauge steel, powder coated |
|
| Shelves (See Accessories)* | 3 standard, 8 total | 3 standard, 16 total | 3 standard, 16 total | |
| Maximum Weight Per Shelf* | 35 lb / 15.8 kg | 35 lb / 15.8 kg | 35 lb / 15.8 kg | |
| Permitted Total Load | 100 lb / 45.3 | 200 lb / 90.7 kg | 200 lb / 90.7 kg | |
| Order Model Number, Voltage Specific | SCO2W | SCO5W | SCO6W | ||||
| SCO2W | SCO2W-2 | SCO5W | SCO5W-2 | SCO6W | SCO6W-2 | ||
| Electrical, 50/60Hz, AC, 1Ø | |||||||
| Voltage | 110V-120V | 220V-240V | 110V-120V | 220V-240V | 110V-120V | 220V-240V | |
| Full Load Amps | 5.0 | 3.5 | 5.0 | 3.5 | 5.0 | 3.5 | |
| Nominal Power (watts @37°C) | 340 | 300 | 420 | 400 | 420 | 400 | |
| Recommended Breaker, Amps | 15 | 15 | 15 | 15 | 15 | 15 | |
| Plug Supplied | NEMA5-15P | EU1-16P | NEMA5-15P | EU1-16P | NEMA5-15P | EU1-16P | |
| CO2 Range | 1-20% | 1-20% | 1-20% | 1-20% | 1-20% | 1-20% | |
| Recovery CO2 at 5%* | < 5 min. | < 5 min. | < 5 min. | < 5 min. | < 5 min. | < 5 min. | |
| Sensor Type | Infrared | Infrared | Infrared | Infrared | Infrared | Infrared | |
| Humidity Range Passive (Ambient 95%) | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | |
| Humidity Display | – | – | ✓ | ✓ | – | – | |
| Temperature Uniformity | |||||||
| At 37°C | ± 0.2°C | ± 0.2°C | ± 0.2°C | ± 0.2°C | ± 0.2°C | ✓ | |
| Temperature Range Recovery 37°C* | |||||||
| Recovery to 37°C after 30 sec. Door Opening | 8.0 min. | 8.0 min. | 5.0 min | 5.0 min | 4.0 min | 4.0 min | |
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Product | SCO2W (100-120V ), SCO2W (220-230V), SCO5W (110-120V ), SCO5W-2 (220-230V), SCO6WE (110-120V ), SCO6WE-2 (220-230V) |
