Basic with motorized lift and digital setting
Features of Rotary evaporator, Glass “A”, Oil Bath (RE301A-O)
- One touch electric lift for easy up and down movement.
- The evaporator’s motor speed (rpm) is digitally set and displayed.
- Unique durable vacuum seal suitable up to 2L flasks.
- Stable rotation at low and high speeds.
- Equipped with lift up switch in case of power outage.
- Removable bath for easy cleaning and water replacement, with the option for water or oil bath.
- Compact design fits into any fume hood.
- Universal power supply: works with 100-240VAC.
Specifications | ||
Item Code | 255423 | |
Model | RE301A-O | |
Motor | DC brushless motor | |
Rotation speed | 20 to 250 (rpm) | |
Lift stroke | 130mm | |
Rotational speed setting | Control knob (digital indication) | |
Safety function (main unit) | Manual-setting lower limit, motor overload | |
Lifting feature | Motorized lifting system | |
External dimensions(W×D×H mm) | 828×400×586mm | |
Remarks(dimensions) | With Glassware A (mm), (716 when raised) | |
Power Source | AC100 to 240V 1.5A | |
Weight | 14.1kg | |
Remarks(weight) | Excluding glassware and water/ oil bath. |
