Freezers and refrigerators, Laboratory Equipment, Low Temp Freezers
LTF001C/LTF101C/LTF201C/LTF301C/LTF401C/LTF501C/LTF601C/LTF801C/LTF901C- Low-Temp LTF Series Horizontal (Chest) Freezers – Yamato
$7,018.00 – $18,166.50
Primary Uses
- Clinics
- Research
- Small laboratories
- Hospital rooms
- Medical clinics
| Models | LTF SERIES | |
| Temperature Range | 0°C ~ -40°C / +32 ~ -40°F | |
| Temperature Control System | Digital Control with two temperature displays. One display shows the set temperature, the other shows the actual temperature in the freezer. |
|
| Digital Alarm System With Relay | Battery operated alarm system will emit an audible and visual signal when there is a mechanical or electrical failure. The alarm has an over and under temperature setting, alarm silencing switch, and battery test switch. Also provided is a relay for remote alarm hook-up. |
|
| Refrigeration System | Single stage system with one hermetic compressor. CFC & HCFC free refrigerants |
|
| Construction | Chamber is 14-ga. zinc coated galvanized steel. Exterior is 16-ga. steel. Powder coated cool gray finish. |
|
| Electrical Requirements | 115V, 60 Hz, 1 phase 208V, 60 Hz, 1 phase 230V, 60 Hz, 1 phase 220V, 50 Hz, 1 phase 220V, 60 Hz, 1 phase |
|
| Optional Accessories | Chart recorder, CO² and LN² back-up system, Racks, Cold safety gloves | |
Primary Uses
- Clinics
- Research
- Small laboratories
- Hospital rooms
- Medical clinics
| Models | CAPACITY | RACK CAPACITY | TEMP. RANGE | INTERNAL DIMENSIONS | EXTERNAL DIMENSIONS | |
| LTF001C | 56L / 2 cu. ft. | 6 | -40ºC to -85ºC | 17” x 14” x 14” 43 x 35 x 35 cm |
25.25″ x 25.75” x 40” 64 x 65 x 101 |
|
| LTF101C | 83L / 3 cu. ft. | 8 | -40ºC to -85ºC | 24” x 12” x 18” 60 x 30 x 45 cm |
34.5″ x 25.25″ x 48″ 87 x 64 x 121 |
|
| LTF201C | 142L / 5 cu. ft. | 15 | -40ºC to -85ºC | 30” x 18” x 16” 76 x 45 x 40 |
40.5” x 31” x 47” 102 x 81 x 119 |
|
| LTF301C | 255L / 9 cu. ft. | 16 | -40ºC to -85ºC | 46” x 16” x 20” 116 x 40 x 50 |
57.5″ x 29″ x 46.5″ 146 x 73 x 116 |
|
| LTF401C | 340L / 12 cu. ft. | 27 | -40ºC to -85ºC | 55” x 19” x 20” 139 x 48 x 50 |
65.5″ x 32″ x 47.5″ 166 x 81 x 120 |
|
| LTF501C | 400L / 14 cu. ft. | 30 | ||||
| Models | LTF SERIES | |||||
| Temperature Range | 0°C ~ -40°C / +32 ~ -40°F | |||||
| Temperature Control System | Digital Control with two temperature displays. One display shows the set temperature, the other shows the actual temperature in the freezer. |
|||||
| Digital Alarm System With Relay | Battery operated alarm system will emit an audible and visual signal when there is a mechanical or electrical failure. The alarm has an over and under temperature setting, alarm silencing switch, and battery test switch. Also provided is a relay for remote alarm hook-up. |
|||||
| Refrigeration System | Single stage system with one hermetic compressor. CFC & HCFC free refrigerants |
|||||
| Construction | Chamber is 14-ga. zinc coated galvanized steel. Exterior is 16-ga. steel. Powder coated cool gray finish. |
|||||
| Electrical Requirements | 115V, 60 Hz, 1 phase 208V, 60 Hz, 1 phase 230V, 60 Hz, 1 phase 220V, 50 Hz, 1 phase 220V, 60 Hz, 1 phase |
|||||
| Optional Accessories | Chart recorder, CO² and LN² back-up system, Racks, Cold safety gloves | |||||
| Models | CAPACITY | RACK CAPACITY | TEMP. RANGE | INTERNAL DIMENSIONS | EXTERNAL DIMENSIONS | |
| LTF001C | 56L / 2 cu. ft. | 6 | -40ºC to -85ºC | 17” x 14” x 14” 43 x 35 x 35 cm |
25.25″ x 25.75” x 40” 64 x 65 x 101 |
|
| LTF101C | 83L / 3 cu. ft. | 8 | -40ºC to -85ºC | 24” x 12” x 18” 60 x 30 x 45 cm |
34.5″ x 25.25″ x 48″ 87 x 64 x 121 |
|
| LTF201C | 142L / 5 cu. ft. | 15 | -40ºC to -85ºC | 30” x 18” x 16” 76 x 45 x 40 |
40.5” x 31” x 47” 102 x 81 x 119 |
|
| LTF301C | 255L / 9 cu. ft. | 16 | -40ºC to -85ºC | 46” x 16” x 20” 116 x 40 x 50 |
57.5″ x 29″ x 46.5″ 146 x 73 x 116 |
|
| LTF401C | 340L / 12 cu. ft. | 27 | -40ºC to -85ºC | 55” x 19” x 20” 139 x 48 x 50 |
65.5″ x 32″ x 47.5″ 166 x 81 x 120 |
|
| LTF501C | 400L / 14 cu. ft. | 30 | -40ºC to -85ºC | 62” x 20” x 20” 157 x 50 x 50 |
72.5″ x 33″ x 47.5″ 184 x 83 x 120 |
|
| LTF601C | 480L / 17 cu. ft. | 36 | -40ºC to -85ºC | 69” x 20” x 21” 175 x 50 x 53 |
81.25″ x 33.5″ x 48.5″ 206 x 85 x 123 |
|
| LTF801C | 626L / 22 cu. ft. | 36 | -40ºC to -85ºC | 67” x 19” x 30” 170 x 48 x 76 |
98” x 36” x 43.5” 248 x 91 x 110 |
|
| LTF901C | 766L / 27 cu. ft. | 48 | -40ºC to -80ºC | 67” x 23” x 31.25” 170 x 57 x 79 |
98” x 36” x 43.5” 248 x 91 x 110 |
|
| -40ºC to -85ºC | 62” x 20” x 20” 157 x 50 x 50 |
72.5″ x 33″ x 47.5″ 184 x 83 x 120 |
||||
| LTF601C | 480L / 17 cu. ft. | 36 | -40ºC to -85ºC | 69” x 20” x 21” 175 x 50 x 53 |
81.25″ x 33.5″ x 48.5″ 206 x 85 x 123 |
|
| LTF801C | 626L / 22 cu. ft. | 36 | -40ºC to -85ºC | 67” x 19” x 30” 170 x 48 x 76 |
98” x 36” x 43.5” 248 x 91 x 110 |
|
| LTF901C | 766L / 27 cu. ft. | 48 | -40ºC to -80ºC | 67” x 23” x 31.25” 170 x 57 x 79 |
98” x 36” x 43.5” 248 x 91 x 110 |
|
| Dimensions | N/A |
|---|---|
| Products | LTF-001C (CHEST STYLE LOW TEMPERATURE FREEZERS 0ºC to -40ºC, 2 cu.ft., Manual Defrost), LTF-101C (CHEST STYLE LOW TEMPERATURE FREEZERS 0ºC to -40ºC, 3 cu.ft., Manual Defrost), LTF-201C (CHEST STYLE LOW TEMPERATURE FREEZERS 0ºC to -40ºC, 5 cu.ft., Manual Defrost), LTF-301C (CHEST STYLE LOW TEMPERATURE FREEZERS 0ºC to -40ºC, 9 cu.ft., Manual Defrost), LTF-401C (CHEST STYLE LOW TEMPERATURE FREEZERS 0ºC to -40ºC, 12 cu.ft., Manual Defrost), LTF-501C (CHEST STYLE LOW TEMPERATURE FREEZERS 0ºC to -40ºC, 14 cu.ft., Manual Defrost), LTF-601C (CHEST STYLE LOW TEMPERATURE FREEZERS 0ºC to -40ºC, 17 cu.ft., Manual Defrost), LTF-801C (CHEST STYLE LOW TEMPERATURE FREEZERS 0ºC to -40ºC, 22 cu.ft., Manual Defrost), LTF-901C (CHEST STYLE LOW TEMPERATURE FREEZERS 0ºC to -40ºC, 27 cu.ft., Manual Defrost) |
