9010-0334,9010-0333 ED 56 Drying & Heating Chamber, 56L Binder
The strengths of a drying chamber of the BINDER ED series are the routine drying and sterilization tasks at temperatures of up to 300 ° C.
$1,832.00
The strengths of a drying chamber of the BINDER ED series are the routine drying and sterilization tasks at temperatures of up to 300 ° C. Thanks to natural convection, in this drying chamber all thermal processes are developed with maximum efficiency. The ED series provides fast and homogeneous drying.
Important characteristics
- Temperature range: ambient temperature plus 5 °C to 300 °C
- Up to 30% lower energy consumption compared to conventional units on the market
- High temperature accuracy thanks to APT.line™ technology
- Natural convection
- Controller with LCD display
- Electromechanical control of the exhaust air flap
- 2 chrome-plated racks
- Stackable
- Class 2 integrated independent adjustable temperature safety device (DIN 12880) with visual alarm
- Ergonomic handle design
- USB port for recording data
| Designation | ED056-230V¹ | ED056UL-120V¹ |
| Option model | Standard | Standard |
| Order number | 9010-0333 | 9010-0334 |
| Measures | ||
| Interior volume [L] | 57 | 57 |
| Net weight of the unit (empty) [kg] | 39 | 39 |
| permitted load [kg] | 70 | 70 |
| Load per rack [kg] | 30 | 30 |
| Doors | ||
| Unit doors | 1 | 1 |
| Internal Dimensions | ||
| Width [mm] | 360 | 360 |
| Height [mm] | 420 | 420 |
| Depth [mm] | 380 | 380 |
| Outer dimensions | ||
| Width net [mm] | 560 | 560 |
| Height net [mm] | 625 | 625 |
| Depth net [mm] | 565 | 565 |
| Wall clearance sidewise [mm] | 100 | 100 |
| Wall clearance back [mm] | 160 | 160 |
| Environment-specific data | ||
| Energy consumption at 150 °C [Wh/h] | 180 | 180 |
| Fixtures | ||
| Number of shelves (std./max.) | 2/4 | 2/4 |
| Performance Data Temperature | ||
| Temperature range 5 °C above ambient temperature to [°C] | 300 | 300 |
| Temperature variation at 150 °C [± K] | 2.3 | 2.3 |
| Temperature fluctuation at 150 °C [± K] | 0.4 | 0.4 |
| Heating-up time to 150 °C [min] | 50 | 50 |
| Recovery time after 30 seconds door open at 150 °C [min] | 19 | 19 |
| Electrical data | ||
| Rated Voltage [V] | 230 | 120 |
| Power frequency [Hz] | 50/60 | 60 |
| Nominal power [kW] | 1.05 | 1.15 |
| Unit fuse [A] | 6.3 | 12.5 |
| Phase (Nominal voltage) [ph] | 1 | 1 |
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Product | 9010-0334(ED 56 Drying & Heating Chamber, 56L, 120V/60Hz), 9010-0333(ED 56 Drying & Heating Chamber, 56L, 230V/50-60Hz) |
